ANSUL K-GUARD 6 Liter Model K01-3 Parts
Find replacement parts for the ANSUL K-GUARD 6 Liter Model K01-3. Search by diagram number, description, or part number. For assistance confirming compatibility or availability, call Fire Safety Supply at 1-800-498-3473.
6 Liter K-GUARD Model K01-3
This parts reference covers the ANSUL K-GUARD 6 Liter Model K01-3. Use the diagram number, component description, and part number when identifying replacement parts. Product links are provided where available.
Match the diagram numbers to the corresponding rows in the parts table below. A dash indicates a component that is not shown or individually numbered on the diagram.
ANSUL K-GUARD K01-3 Parts List
| Diagram No. | Description | Part No. |
|---|---|---|
| 1 | Valve assembly | 451077 |
| 2 | Lever | 428428 |
| 3 | Handle | 428429 |
| 4 | Ring pin | 429290 |
| 5 | Rivet | 430250 |
| 6 | Gauge, 100 psi | 429536 |
| 7 | Collar nut | 430274 |
| 8 | Collar O-ring #215 | 56909 |
| 9 | Valve stem O-ring #6 | 429159 |
| 10 | Valve stem | 429099 |
| 11 | Spring | 430004 |
| 12 | Fill tube | 429541 |
| 13 | Pick-up tube assembly | 451075 |
| 14 | Hose retainer | 427995 |
| 15 | Nozzle tip | 439382 |
| 16 | Hose and nozzle assembly | 439495 |
| 17 | Hose O-ring #14 | 429544 |
| 18 | Wall hanger | 451409 |
| - | Heavy duty bracket (not shown) | 30937 |
| - | Visual inspection seal (not shown) | 25940 |
| - | Warning placard, English/French/Spanish (not shown) | 426021 |
| - | Refill agent, 1.6 l ANSULEX low pH | 451410 |
Important: Confirm the complete extinguisher model, diagram number, component description, and part number before ordering. Availability and supersession status should also be verified.
Model Reference
- Series: ANSUL K-GUARD
- Model: K01-3
- Capacity: 6 Liter
- Recharge Agent Listed: 1.6 l ANSULEX low pH, Part No. 451410
