Wheeled Halotron I Extinguisher Parts
Models include: B673 - 65 lb Halotron I Wheeled, B674 - 150 lb with 16" semi-pneumatic non-galvanized wheels, and B675 - 150 lb with 36" x 2-1/2" steel wheels with rubber tread.
65 lb. Halotron I - Stored Pressure Wheeled
150 lb. Halotron I - Stored Pressure Wheeled
Important Notes
View Diagram
65 lb. Halotron I - Stored Pressure Wheeled
Models include: B673 - 65 lb Halotron Wheeled
| Item # | Part # | Description |
|---|---|---|
| 1 | 24760 | Valve Assembly Complete with Downtube |
| 2 | 24795 | Downtube/Retainer Assembly |
| 3 | 16724 | Carriage Assembly without Wheels |
| 4 | 16690 | Hose Support with Mounting Hardware |
| 5 | 06130 | Nozzle Mount with Hardware |
| 6 | 07481 | Pictogram |
| 7 | 23837 | Wheel Assembly - 16” with Hub Cap, Washer and Retaining Pin - Semi-Pneumatic |
| 8 | 04945 | Hub Cap |
| 9 | 06059 | Valve Lever with Screws |
| 10 | 16723 | Gauge Guard with Screws |
| 11 | 14417 | Gauge - 100 PSI |
| 12 | 06100 | Ring Pin, Stainless Steel with Wire |
| 13 | 01387 | Lock Wire Seal (Yellow) |
| 14 | 22979 | Valve Body |
| 15 | 06060 | Cam Assembly with O-Rings |
| 16 | 16664 | Collar O-Ring |
| 17 | 23811 | Valve Stem Assembly |
| 18 | 22983 | Spring |
| 19 | 03501 | Hose Assembly - 3/4” x 50’ |
| 20 | 06279 | Ball Valve Assembly |
| 21 | 03877 | Gasket, Hose/Nozzle |
| 22 | 24775 | Nozzle Tip (.330) |
| 23* | 25025 | Nameplate |
| 24 | 03562 | Gauge Guard |
150 lb. Halotron I - Stored Pressure Wheeled
Models include: B674 - 16" semi-pneumatic non-galvanized wheels and B675 - 36" x 2-1/2" steel wheels with rubber tread.
| Item # | Part # | Description |
|---|---|---|
| 1 | 23808 | Valve Assembly Complete with Downtube |
| 2 | 23809 | Downtube/Retainer Assembly |
| 3 | 16727 | Carriage Assembly without Wheels - B674 |
| 4 | 16725 | Hose Support with Mounting Hardware |
| 5 | 07481 | Pictogram |
| 6 | 07026 | Wheel Assembly - 36” x 6” - 675 (Optional B675) |
| 7 | 07050 | Wheel Assembly - 36” x 2 1/2” - B675 |
| 8 | 23837 | Wheel Assembly - 16” with Hub Cap, Washer and Retaining Pin, Semi-Pneumatic, Non-Galvanized - B674 |
| 9 | 16984 | Hub Cap for 36” Wheels |
| 07389 | Hub Cap for 36” Wheels with Washer and Cotter Pin | |
| 10 | 04945 | Hub Cap |
| 11 | 06059 | Valve Lever with Screws |
| 12 | 16723 | Gauge Guard with Screws |
| 13 | 16332 | Gauge - 150 PSI |
| 14 | 06100 | Ring Pin, Stainless Steel with Wire |
| 15 | 01387 | Lock Wire Seal (Yellow) |
| 16 | 22979 | Valve Body |
| 17 | 06060 | Cam Assembly with O-Rings |
| 18 | 16664 | Collar O-Ring |
| 19 | 23811 | Valve Stem Assembly |
| 20 | 22983 | Spring |
| 21 | 03501 | Hose Assembly - 3/4” x 50’ |
| 22 | 06279 | Ball Valve Assembly |
| 23 | 03877 | Gasket, Hose/Nozzle |
| 24 | 23665 | Nozzle Tip (.692) |
| 25* | 25027 | Nameplate |
| 26 | 03562 | Gauge Guard |
Important Notes
Replacement Valve Assemblies include Valve Body, Gauge, Gauge Guard, Cam, Lever, Valve Stem Assembly, Spring and Downtube/Retainer Assembly.
*Nameplates do not include UL or USCG Listing.
