Wheeled High Performance Stored Pressure Extinguisher Parts
125/250 lb Wheeled - Dry Chemical Stored Pressure - High Performance & Z-Series
View Parts Table Additional Resources View Graphics
Models Include:
573 - 250 lb ABC, 575 - 250 lb Purple K, 690 - 125 lb Purple K, 756 - 250 lb ABC, 758 - 250 lb Purple K, 759 - 125 lb Purple K
573 - 250 lb ABC, 575 - 250 lb Purple K, 690 - 125 lb Purple K, 756 - 250 lb ABC, 758 - 250 lb Purple K, 759 - 125 lb Purple K
| Item # | Part # | Description |
|---|---|---|
| 1 | 08715 | Valve Assembly Complete with Downtube |
| 05197 | Valve Assembly Complete with Downtube - 690, 759 | |
| 2 | 09856 | Downtube/Retainer Assembly |
| 04938 | Downtube/Retainer Assembly - 690, 759 | |
| 3 | 09300 | Cap, Agent Cylinder |
| 4 | 08392 | Gasket, Fill Cap |
| 5 | 27087 | Carriage Asy Z-Series without Wheels |
| 27086 | Carriage Asy Z-Series without Wheels - 690, 759 | |
| 6 | 07481 | Pictogram - 573, 756 |
| 07483 | Pictogram - 575, 574, 690, 757, 758, 759 | |
| 7 | 27078 | Hose Support Assembly |
| 27077 | Hose Support Asseembly - 690, 759 | |
| 8 | 27226 | Wheel Assembly Z-Series 36” x 6” |
| 27071 | Wheel Assembly 36” x 6” (Vulcanized Rubber Wheel for 756R, 758R, 759R) | |
| 9 | 07389 | Hub Cap with Washer and Cotter Pin |
| 16984 | Hub Cap | |
| 10 | 06059 | Valve Lever with Screws |
| 11 | 16723 | Gauge Guard with Screws |
| 12 | 08714 | Gauge - 350 PSI |
| 05225 | Gauge - 240 PSI - 690, 759 | |
| 13 | 06100 | Ring Pin, Stainless Steel with Wire |
| 14 | 07309 | Pressure Valve |
| 03559 | Pressure Valve - 690, 759 | |
| 15 | 07310 | Cap for Pressure Valve |
| 00158 | Cap for Pressure Valve - 690, 759 | |
| 16 | 01387 | Lock Wire Seal (Yellow) |
| 17 | 06060 | Cam Assembly with O-Rings |
| 18 | 08573 | Safety Disc Assembly (except 690, 759) |
| 13956 | Protective Vinyl Cap | |
| 14218 | Pipe Plug - 690, 759 | |
| 19 | 03678 | Valve Body |
| 20 | 05239 | Collar O-Ring |
| 21 | 05067 | Valve Stem Assembly |
| 22 | 03556 | Spring |
| 23 | 03877 | Gasket, Hose / Nozzle |
| 24 | 06279 | Ball Valve Assembly |
| 25 | 09399 | Nozzle Tip - 573, 756, (.625) |
| 08260 | Nozzle Tip - 575, 690, 758, 759 (.531) | |
| 26 | 06814 | Hose Assembly 1 in. X 50 ft. |
| 27* | 27082 | Nameplate 756 |
| 27069 | Nameplate 758 | |
| 27075 | Nameplate 759 | |
| 28 | 03562 | Gauge Guard |
Additional Resources
All Brackets
Visit the Brackets Page »
All Fill & Hydrotest Adapters
Visit the Adapters Page »
Notes:
- Replacement Valve Assemblies include Valve Body, Gauge, Gauge Guard, Safety Disc Assembly, Cam, Pressure Valve & Cap, Lever, Valve Stem Assembly, Spring and Downtube/Retainer Assembly (as required).
- *Nameplates do not include UL or USCG Listing.
